Dimension Guide for IMADA Force Gauge Digital DSV Handheld Series (Res: 0.01 Ncm/0.001 Nm/0.01 Nm, Sampling 2000Hz) Range: 2N to 1000N :
Specification Guide for IMADA Force Gauge Digital DST Handheld Series (Res: 0.01 Ncm/0.001 Nm/0.01 Nm, Sampling 2000Hz) Range: 2N to 1000N:
Model |
ZTA |
ZTS |
Feature |
Advanced model with various functions such as data saving
in USB memory stick, displacement I/O and more. |
Standard model with the same benefit in performance as ZTA series but reduced functions. |
Accuracy |
+/-0.2%F.S.+/-1digit |
Unit of measurement (*1) |
N, kgf, lbf (*2) |
Display |
4-digit LCD |
Display update |
16 times / sec. |
Sampling rate |
2000 data / sec. (max) (*3) |
Battery |
8 hours (2 hours charge)(*4) |
Safe overload rating |
Approx.200%F.S. |
Operating environment |
Temperature: 0 to +40 degree Celsius Humidity: 20 to 80%RH |
Function |
Customized display (header and footer), Peak hold (tension and compression),
Internal 1000 points data memory,
Comparator (judgment of acceptance or rejection), Reversible display, Sign inversion,
Zero clear timer, +NG alarm, Off timer (auto power off), Dumping, Date/time display, Setting lock |
1st/2nd peak, Displacement detection at force peak value, Displacement zero reset at selected force |
– |
Output |
USB, RS232C, Mitutoyo digimatic (*5), +/-2VDC analog output (D/A), Comparator 3 steps (-NG/OK/+NG) |
Sub comparator 2 steps (output of large or small judgment)USB flash drive, Displacement |
– |
Overload warning |
Approx.110%F.S. (Warning message shows up and alarm goes off ) |
Available linear scales (*6) |
– Online driver output (a line receiver according to RS422/485 must be built in.)
– Open collector output (Voltage drop between contacts must be smaller than 0.5V.) |
– |
External connecting switch |
SEND (a point of contact holding), Zero reset, Peak ON/OFF setting |
Weight |
Approx.1100g (*7) |
Dimensions |
Please refer to dimensions. |
Accessory(*6) |
AC adapter, Inspection certificate, CD driver (including simple software for data log),
Attachments (The set of attachments varies according to range.), USB cable, Carrying case. |
Adapter for USB flash draive (*8) |
– |
NOTES:
*1 These are the specifications for International model. Note that the available units are different from Japanese domestic model and international one. kN is available at 1000N, mN and gf is available at 2N and 5N ranges.
*2 You cannot use Continuous peak mode when the measurement does not reach 10% of the force gauge’s capacity. Instead, use Peak mode. Continuous peak mode could not fit enough for measurement with a shock such as break tests. Contact us for further details.
*3 The weights are slightly different by the model.
Ordering Guide for IMADA Force Gauge Digital ZTS Standard series (Res: 0.01 Ncm/0.001 Nm/0.01 Nm, Sampling 2000Hz) Range: 2N to 1000N:
Order Code |
Capacity
in N |
Resolution
in N |
Measuring Range
in gf; kgf |
Measuring Range
in ozf; lbf |
DSV-2N |
0 – 2 N |
0.001 N |
0 – 200.0 gf |
0 – 8.819 ozf |
DSV-5N |
0 – 5 N |
0.001 N |
0 – 500.0 gf |
0 – 17.64 ozf |
DSV-20N |
0 – 20 N |
0.01 N |
0 – 2.000 kgf |
0 – 4.409 lbf |
DSV-50N |
0 – 50 N |
0.01 N |
0 – 5.000 kgf |
0 – 11.02 lbf |
DSV-200N |
0 – 200 N |
0.1 N |
0 – 20.00 kgf |
0 – 44.09 lbf |
DSV-500N |
0 – 500 N |
0.1 N |
0 – 50.00 kgf |
0 – 110.2 lbf |
DSV-1000N |
0 – 1000 N |
1 N |
0 – 100.0 kgf |
0 – 220.5 lbf |
