Dimension Guide for INSIZE Brinell Hardness Tester Static Type ISHB-P101, ISO 6506, ASTM E10, Identer; Ø7,26mm/Ø4mm, Range; 100HBW ~ 650HBW :
Ordering Guide of INSIZE Brinell Hardness Tester Static Type ISHB-P101, ISO 6506, ASTM E10, Identer; Ø7,26mm/Ø4mm, Range; 100HBW ~ 650HBW :
Order Code |
ISHB-H131 |
Measuring range |
100-350 HBW (including 7.26 mm probe)
350-650 HBW (with optional 4 mm probe) |
Measuring force |
1580 kg |
Accuracy |
Static test: ±3%
Impact test: ±5% |
Microscope |
20X, resolution 0.01 mm |
Maximum workpiece height of static test |
150 mm |
Maximum workpiece width of static test |
80 mm |
Size |
195 x 60 x 350 mm |
Mass |
4.2 kg |
FULL DELIVERY SET |
Static test clamp |
1 PC |
Impact test clamp |
1 PC |
Flat anvil |
1 PC |
V-shaped anvil |
1 PC |
Probe 7.26 mm |
1 PC |
Hardness test block |
1 PC |
Test pin |
250 pcs |
Microscope |
1 PC |
OPTIONAL ACCESSORIES |
Measuring head Φ4 mm |
ISHB-P101-INDENTER |
Test pin 250 pcs |
ISHB-P101-PIN |
