Specification Guide for INSIZE Coating Thickness Gauge (0-1250µm) non-magnetic coating on ferrous 9501-1200:
Ordering Guide for INSIZE Coating Thickness Gauge (0-1250µm) non-magnetic coating on ferrous 9501-1200:
Probe type |
FE (included) magnetic induction probe |
NFE (optional) eddy current probe |
FE70 (optional) magnetic induction probe for bores and grooves |
FE50 (optional) magnetic induction probe for larger range |
Measuring range |
0~1250μm |
0~1250μm |
0~1250μm |
500-10000μm |
Accuracy |
±(3%L+1)μm
±(3%L+10)μm |
(range<1250μm)
(range>1250μm) |
L is measuring thickness in μm |
|
Resolution |
0.1μm(range<100μm) |
1μm(range<100μm) |
Measuring mode |
continuous and single |
Minimum substrate thickness |
0.5mm |
0.3mm |
0.5mm |
2mm |
Minimum measuring area |
⌀ 7mm |
⌀ 5mm |
⌀ 7mm |
⌀ 40mm |
Minimum curvature radius curvature radius of convex workpiece |
1.5mm |
3mm |
– |
10mm |
Memory |
500 |
Output |
USB |
Powersupply |
2 x 1.5V AA batteries |
Dimension |
128x68x32mm |
Weight |
340g |
INSIZE Coating Thickness Gauge (0-1250µm) non-magnetic coating on ferrous 9501-1200 Selectable Probes & Application Guide:
Data transmission cable |
9501-1200-SPC |
Eddy current probe (NFE) with zero calibration block |
9501-1200-NFE |
Magnetic induction probe (FE90) for bores and grooves |
9501-1200-FE90 |
Magnetic induction probe (FE10) with big range |
9501-1200-FE10 |
