Specification of INSIZE Digital Inside Groove Caliper 1128 (DIN862, Grad; 0.01mm) Accuracy; ±0.02mm, Range; ≤Ø200mm :
Order Guide for INSIZE Digital Inside Groove Caliper 1128 (DIN862, Grad; 0.01mm) Accuracy; ±0.02mm, Range; ≤Ø200mm :
No dust/waterproof, preset (no need to add the width of the jaws on the reading), with data interface (mm) |
Order Code |
Range |
Type |
Accuracy |
L |
a |
3 |
c |
d |
e |
Data output cable (optional) |
1120-150A |
22-150mm/0.87-6″ |
A |
±0.04mm |
250 |
5 |
11 |
16 |
30 |
1 |
7315-21, 7302-21 |
1120-1501 |
35-150mm/1.38-6″ |
A |
±0.06mm |
250 |
6 |
17.5 |
16 |
60 |
1.5 |
7315-21, 7302-21 |
1120-200A |
25-200mm/0.98-8″ |
A |
±0.04mm |
310 |
5 |
12.5 |
16 |
40 |
1 |
7315-21, 7302-21 |
1120-2001 |
40-200mm/1.57-8″ |
A |
±0.06mm |
310 |
7 |
20 |
16 |
70 |
2.5 |
7315-21, 7302-21 |
1120-300A |
30-300mm/1.18-12″ |
A |
±0.05mm |
410 |
5 |
15 |
16 |
50 |
1.5 |
7315-21, 7302-21 |
1120-3001 |
50-300mm/1.97-12″ |
A |
±0.07mm |
410 |
8 |
25 |
16 |
80 |
2.5 |
7315-21, 7302-21 |
1120-500 |
40-500mm/1.57-20″ |
A |
±0.07mm |
680 |
5 |
20 |
24 |
90 |
2.2 |
7315-22, 7302-22 |
1120-5001 |
60-500mm/2.36-20″ |
A |
±0.08mm |
680 |
10 |
30 |
24 |
120 |
3.4 |
7315-22, 7302-22 |
1120-5002 |
80-500mm/3.15-20″ |
A |
±0.08mm |
680 |
16 |
40 |
24 |
150 |
5.2 |
7315-22, 7302-22 |
Order Guide for INSIZE Digital Inside Groove Caliper 1128 WIRELESS (DIN862, Grad; 0.01mm) Accuracy; ±0.02mm, Range; ≤Ø200mm :
No dust/waterproof, preset (no need to add the width of the jaws on the reading), built-in wireless (receiver code 7315-2/3/6/7/8 is required) |
Order Code |
Range |
Type |
Accuracy |
L |
a |
3 |
c |
d |
e |
1120-150AWL |
22-150mm/0.87-6″ |
A |
±0.04mm |
250mm |
5mm |
11mm |
16mm |
30mm |
1mm |
1120-1501WL |
35-150mm/1.38-6″ |
A |
±0.06mm |
250mm |
6mm |
17.5mm |
16mm |
60mm |
1.5mm |
1120-200AWL |
25-200mm/0.98-8″ |
A |
±0.04mm |
310mm |
5mm |
12.5mm |
16mm |
40mm |
1mm |
1120-2001WL |
40-200mm/1.57-8″ |
A |
±0.06mm |
310mm |
7mm |
20mm |
16mm |
70mm |
2.5mm |
1120-300AWL |
30-300mm/1.18-12″ |
A |
±0.05mm |
410mm |
5mm |
15mm |
16mm |
50mm |
1.5mm |
1120-3001WL |
50-300mm/1.97-12″ |
A |
±0.07mm |
410mm |
8mm |
25mm |
16mm |
80mm |
2.5mm |
1120-500WL |
40-500mm/1.57-20″ |
A |
±0.07mm |
680mm |
5mm |
20mm |
24mm |
90mm |
2.2mm |
1120-5001WL |
60-500mm/2.36-20″ |
A |
±0.08mm |
680mm |
10mm |
30mm |
24mm |
120mm |
3.4mm |
1120-5002WL |
80-500mm/3.15-20″ |
A |
±0.08mm |
680mm |
16mm |
40mm |
24mm |
150mm |
5.2mm |
Order Guide for INSIZE Digital Inside Groove Caliper 1128 STANDARD (DIN862, Grad; 0.01mm) Accuracy; ±0.02mm, Range; ≤Ø200mm :
No dust/waterproof, no preset (need to add the width of the jaws on the reading) |
Order Code |
Range |
Type |
Accuracy |
L |
a |
3 |
c |
d |
e |
1120-150B |
50-150mm/1.97-6″ |
B |
±0.06mm |
270mm |
8mm |
25mm |
20mm |
90mm |
3.4mm |
1120-200B |
60-200mm/2.36-8″ |
B |
±0.06mm |
320mm |
10mm |
30mm |
20mm |
100mm |
3.4mm |
1120-300B |
60-300mm/2.36-12″ |
B |
±0.07mm |
420mm |
10mm |
30mm |
20mm |
110mm |
3.4mm |
Order Guide for INSIZE Digital Inside Groove Caliper 1128 WATERPROOF IP67 (DIN862, Grad; 0.01mm) Accuracy; ±0.02mm, Range; ≤Ø200mm :
IP67 dust/waterproof, no automatic power off, set zero after power on each time, no preset (need to add the width of the jaws on the reading), without data interface |
Code |
Range |
Type |
Accuracy |
L |
a |
3 |
c |
d |
e |
1120-150P |
22-150mm/0.87-6″ |
C |
±0.04mm |
250mm |
5mm |
11mm |
16mm |
30mm |
1mm |
