Specification of INSIZE Digital Caliper 1171 (DIN862, Grad; 0.01mm) Accuracy; ±0.03mm, Range; ≤Ø200mm – Ø300mm:
Order Guide for INSIZE Digital Caliper 1171 (DIN862, Grad; 0.01mm) Accuracy; ±0.03mm, Range; ≤Ø200mm – Ø300mm:
With data interface (data output cable code 7315-21, 7302-21, optional) |
Order Code |
Range |
Accuracy |
a |
b |
c |
d |
e |
L |
1171-200 |
0-200mm/0-8″ |
±0.03mm |
12mm |
38mm |
17mm |
60mm |
10mm |
320mm |
1171-250 |
0-250mm/0-10″ |
±0.03mm |
12mm |
38mm |
17mm |
60mm |
10mm |
365mm |
1171-306 |
0-300mm/0-12″ |
±0.04mm |
12mm |
38mm |
17mm |
60mm |
10mm |
420mm |
1171-300 |
0-300mm/0-12″ |
±0.06mm |
12mm |
38mm |
17mm |
90mm |
10mm |
420mm |
Built-in wireless |
Order Code |
Range |
Accuracy |
a |
b |
c |
d |
e |
L |
1171-200WL |
0-200mm/0-8″ |
±0.03mm |
12mm |
17mm |
17mm |
60mm |
10mm |
320mm |
1171-250WL |
0-250mm/0-10″ |
±0.03mm |
12mm |
17mm |
17mm |
60mm |
10mm |
365mm |
1171-306WL |
0-300mm/0-12″ |
±0.04mm |
12mm |
17mm |
17mm |
60mm |
10mm |
420mm |
1171-300WL |
0-300mm/0-12″ |
±0.06mm |
12mm |
17mm |
17mm |
90mm |
10mm |
420mm |
