Dimension Guide for INSIZE Digital Crane Weighing Scale 8205 (Remote display, alloy casting) Range; 2 Ton – 10 Ton:
Order Guide of INSIZE Digital Crane Weighing Scale 8205 (Remote display, alloy casting) Range; 2 Ton – 10 Ton:
Order Code |
L |
G |
ØD2 |
H |
ØD1 |
W |
B |
ØB |
8205-2T |
319 |
126 |
72 |
88 |
132 |
198 |
34 |
48 |
8205-3T |
319 |
126 |
72 |
88 |
132 |
198 |
34 |
48 |
8205-5T |
407 |
161 |
88 |
105 |
160 |
219 |
42 |
57 |
8205-10T |
465 |
202 |
95 |
105 |
170 |
246 |
46 |
65 |
8205-15T |
520 |
203 |
120 |
130 |
215 |
263 |
60 |
77 |
8205-20T |
621 |
284 |
142 |
135 |
251 |
294 |
75 |
105 |
8205-30T |
770 |
305 |
180 |
205 |
325 |
356 |
85 |
125 |
8205-50T |
1020 |
470 |
200 |
340 |
360 |
436 |
135 |
170 |
Technical Guide of INSIZE Digital Crane Weighing Scale 8205 (Remote display, alloy casting) Range; 2 Ton – 10 Ton:
Overload alarm |
100%F.S.+9e |
Maximum safe load |
150%F.S. |
Limited overload |
400%F.S. |
Stable reading time |
≤8s |
Power supply |
rechargeable battery 4.2V/1A (for 40 hours working) |
Operation temperature |
-10~40°С |
Operation humidity |
≤85% RH |
Order Code |
8205-2T |
8205-3T |
8205-5T |
8205-10T |
Maximum weighing |
2t |
3t |
5t |
10t |
Minimum weighing |
10kg |
20kg |
40kg |
100kg |
Resolution (d) |
1kg/0.5kg |
1kg/0.5kg |
2kg/1kg |
5kg |
Accuracy (m is load) |
m≤0.5t: ±0.5kg; m>0.5t: ±1kg |
m≤0.5t: ±0.5kg; 0.5t<m≤2t: ±1kg; m>2t: ±1.5kg |
m≤1t: ±1kg; 1t<m≤4t: ±2kg; m>4t: ±3kg |
m≤2.5t: ±2.5kg; m>2.5t: ±5kg |
Order Code |
8205-15T |
8205-20T |
8205-30T |
8205-50T |
Maximum weighing |
15t |
20t |
30t |
50t |
Minimum weighing |
100kg |
200kg |
200kg |
400kg |
Resolution (d) |
5kg |
10kg |
10kg |
20kg |
Accuracy (m is load) |
m≤2.5t: ±2.5kg; 2.5t<m≤10t: ±5kg; m>10t: ±7.5kg |
m≤5t: ±5kg; m>5t: ±10kg |
m≤5t: ±5kg; 5t<m≤20t: ±10kg; m>20t: ±15kg |
m≤10t: ±10kg; 10t<m≤40t: ±20kg; m>40t: ±30kg |
STANDARD DELIVERY |
Main unit |
1 pc |
Remote controller |
1 pc |
OPTIONAL ACCESSORY |
Wireless printer |
8205-PRINTER (must be supplied with scales together) |
Large display |
8205-SCREEN (must be supplied with scales together) |
Wireless receiver (serial port signal, connect to computers) |
8205-RECEIVER (must be supplied with scales together) |
