Dimension Guide of INSIZE Disk Micrometer 3353-WL, WIFI Output, Resolution 0.0002mm, ⌀25mm – ⌀100mm IP65 :
Order Guide of INSIZE Disk Micrometer 3353, Cable Output, Resolution 0.0002mm, ⌀25mm – ⌀100mm IP65 :
Order Code |
Range |
Accuracy |
Repeatability |
Parallelism |
A |
B |
3353-25 * |
0-25mm/0-1″ |
4µm |
1µm |
4µm |
38mm |
24mm |
3353-50 * |
25-50mm/1-2″ |
4µm |
1µm |
4µm |
63mm |
25mm |
3353-75 * |
50-75mm/2-3″ |
5µm |
1µm |
5µm |
88mm |
42mm |
3353-100 * |
75-100mm/3-3.95″ |
5µm |
1µm |
5µm |
113mm |
56mm |
3353-125 * |
100-125mm/4-5″ |
6µm |
2µm |
6µm |
128mm |
62.5mm |
3353-150 * |
125-150mm/5-6″ |
6µm |
2µm |
6µm |
153mm |
75mm |
Data Cable aksesori opsional:
Adapter pemancar wireless kode 7315-60, Adapter penerima kode 7315-2, 7315-3
Kabel output data (format keyboard), kode 7302-60
Kabel output data (format port serial), kode 7305-G60, (panjang kabel 3m, panjang kabel opsional maksimum 15m; protokol RS232, protokol RS485 opsional)
Order Guide of INSIZE Disk Micrometer 3353-WL, WIFI Output, Resolution 0.0002mm, ⌀25mm – ⌀100mm IP65 :
Order Code |
Range |
Accuracy |
Repeatability |
Parallelism |
A |
B |
3353-25WL* |
0-25mm/0-1″ |
4µm |
1µm |
4µm |
38mm |
24mm |
3353-50WL* |
25-50mm/1-2″ |
4µm |
1µm |
4µm |
63mm |
25mm |
3353-75WL* |
50-75mm/2-3″ |
5µm |
1µm |
5µm |
88mm |
42mm |
3353-100WL* |
75-100mm/3-3.95″ |
5µm |
1µm |
5µm |
113mm |
56mm |
3353-125WL* |
100-125mm/4-5″ |
6µm |
2µm |
6µm |
128mm |
62.5mm |
3353-150WL* |
125-150mm/5-6″ |
6µm |
2µm |
6µm |
153mm |
75mm |
Built-in Wireless bawaan, aksesori opsional:
Adapter penerima nirkabel (format keyboard), kode 2134-R1
Adapter penerima nirkabel (format port serial), kode 2134-R2
