Ordering Guide of INSIZE Digital Measuring Microscope 5318-MD60 (2Mpx, Res; 1920×1080, 1/2.8″ Inch CMOS, USB, HDMI) LCD 13,3 Inch, Zoom Magnification; 12.5X – 80X:
Specification Guide of INSIZE Digital Measuring Microscope 5318-MD60 (2Mpx, Res; 1920×1080, 1/2.8″ Inch CMOS, USB, HDMI) LCD 13,3 Inch, Zoom Magnification; 12.5X – 80X:
Order Code |
5318-MD60 (without stage) |
5318-MD60-XY (with stage) |
Magnification |
12.5X~80X |
12.5X~80X |
Sensor |
1/2.8” CMOS |
1/2.8” CMOS |
Pixel |
2M |
2M |
Resolution |
1920×1080 |
1920×1080 |
Frame rate |
60fps |
60fps |
Measuring accuracy |
±0.02mm |
±0.02mm |
Lines |
Cross lines, scale lines
(number, color and position of lines are adjustable) |
Cross lines, scale lines
(number, color and position of lines are adjustable) |
Output |
HDMI |
HDMI |
Power supply |
Power adapter |
Power adapter |
Dimension (L×W×H) |
380×260×350mm |
570×300×430mm |
Weight |
4.5kg |
10kg |
STANDARD DELIVERY |
Order Code |
5318-MD60 (without stage) |
5318-MD60-XY (with stage) |
Main unit |
1 pc |
1 pc |
0.5X camera adapter |
1 pc |
1 pc |
1X auxiliary objective |
1 pc |
1 pc |
White/black plate |
1 pc |
1 pc |
Glass calibration rule |
1 pc |
1 pc |
16G USB flash disk |
1 pc |
1 pc |
Mouse |
1 pc |
1 pc |
HDMI cable |
1 pc |
1 pc |
Power adapter |
3 pcs |
3 pcs |
X-Y metal stage |
– |
1 pc |
MAGNIFICATION & VIEWFIELD |
Auxiliary objective |
Specification |
Camera adapter |
0.5X (included) |
0.5X (optional) |
Magnification |
6.2~40X |
View field |
47×26~7.4×4mm |
1X (included) |
Magnification |
12.5~80X |
View field |
23.5×13~3.7×2mm |
2X (optional) |
Magnification |
25~160X |
View field |
11.8×6.5~1.8×1mm |
OPTIONAL ACCESSORY |
0.5X auxiliary objective |
5318-OB05X |
2X auxiliary objective |
5318-OB2X |
