Dimension Guide of INSIZE Digital Micrometer 3109 (Basic Type, Graduation: 0.001mm) Accuracy; ±2µm, Range; ≤Ø25mm – Ø200mm:
Order Guide of INSIZE Digital Micrometer 3109 (Basic Type, Graduation: 0.001mm) Accuracy; ±2µm, Range; ≤Ø25mm – Ø200mm:
Metric/Inch type (Friction thimble) |
(mm) |
Order Code |
Range |
Resolution |
Accuracy |
L |
a |
b |
c |
3109-25* |
0-25mm/0-1″ |
0.001mm/0.00005″ |
±2μm |
34.5 |
6 |
25 |
3 |
3109-50* |
25-50mm/1-2″ |
0.001mm/0.00005″ |
±2μm |
59.5 |
8 |
32 |
3 |
3109-75* |
50-75mm/2-3″ |
0.001mm/0.00005″ |
±3μm |
84.5 |
8 |
44.5 |
3 |
3109-100* |
75-100mm/3-7″ |
0.001mm/0.00005″ |
±3μm |
109.5 |
8 |
57 |
3 |
3109-125 |
100-125mm/7-5″ |
0.001mm/0.00005″ |
±3μm |
135 |
10 |
70 |
3 |
3109-150 |
125-150mm/5-6″ |
0.001mm/0.00005″ |
±3μm |
160.5 |
10 |
82 |
3 |
3109-175 |
150-175mm/6-7″ |
0.001mm/0.00005″ |
±4μm |
186 |
12 |
97.5 |
5.5 |
3109-200 |
175-200mm/7-8″ |
0.001mm/0.00005″ |
±4μm |
211.5 |
12 |
107 |
5.5 |
Order Set (ratchet stop type) |
|
Order Code |
Range |
Micrometers included |
Packaging |
|
3109-753A* |
0-75mm/0-3″ |
3109-25, 3109-50, 3109-75 |
blow mould case |
|
3109-1004A* |
0-100mm/0-7″ |
3109-25, 3109-50, 3109-75, 3109-100 |
blow
mould case |
|
3109-1506A |
0-150mm/0-6″ |
3109-25, 3109-50, 3109-75, 3109-100, 3109-125, 3109-150
|
aluminum box |
|
*Supplied with manufacturer inspection certificate traceable to DKD Germany
