Ordering Guide of INSIZE Digital Microscope 5309-DM50 (2Mpx, Res; 1920×1080, 1/2.8″ Inch CMOS, USB, HDMI) LCD 15,6 Inch, Zoom Magnification; 6.6X ~39.4X:
Specification Guide of INSIZE Digital Microscope 5309-DM50 (2Mpx, Res; 1920×1080, 1/2.8″ Inch CMOS, USB, HDMI) LCD 15,6 Inch, Zoom Magnification; 6.6X ~39.4X:
Order code |
5309-DM50 |
5309-DM51 |
Shaft arm type |
Straight |
Versatile |
Sensor |
1/2.8” CMOS |
Pixels |
2 M |
Resolution |
1920 x 1080 |
Exposure |
real-time auto, one-time auto, manual adjustment |
White balance |
real-time auto, auto once, manual RGB adjustment |
Data Format |
photo (JPG), video (MOV) |
Working distance |
46~186 mm |
46~320 mm |
Magnification |
6.6~39.4X |
3.8~39.4X |
Field of view |
7×4~42×24 mm |
7×4~71×40 mm |
Power supply |
DC 12 V 3 A |
MAGNIFICATION, FIELDS, PRECISION |
Magnification |
Field of view |
Accuracy |
6.6X |
42.0×24.0 mm |
±0.02 mm |
7.3X |
37.8×21.5 mm |
±0.02 mm |
8.9X |
30.9×16.2 mm |
±0.02 mm |
10.8X |
25.7×14.5 mm |
±0.02 mm |
13.8X |
20.1×10.8 mm |
±0.02 mm |
15.2X |
18.2×10.0 mm |
±0.02 mm |
18.5X |
15.0×8.5 mm |
±0.01 mm |
25.2X |
11.1×6.1 mm |
±0.01 mm |
31.5X |
8.8×5.0 mm |
±0.01 mm |
39.4X |
7.0×4.0 mm |
±0.01 mm |
FULL DELIVERY SET |
Main machine |
1 PC |
8GB memory card and carrying case |
1 PC |
Calibration plastic rod |
1 PC |
White/black disc |
1 PC |
Control |
1 PC |
USB cable |
1 PC |
Software |
1 PC |
Adapter |
1 PC |
