Specification Guide for INSIZE Pallet Jack Weight Scales 8801 (Resolution; 0.5kg, Accuracy; ±1kg ) Range; 10kg – 2500kg:
Ordering Guide for INSIZE Pallet Jack Weight Scales 8801 (Resolution; 0.5kg, Accuracy; ±1kg ) Range; 10kg – 2500kg:
ORDER CODE |
8801-A15 |
8801-A20 |
8801-A25 |
8801-B15 |
8801-B20 |
8801-B25 |
Maximum weighting |
1500kg |
2000kg |
2500kg |
1500kg |
2000kg |
2500kg |
Minimum weighting |
10kg |
20kg |
20kg |
10kg |
20kg |
20kg |
Resolution |
0.5kg |
1kg |
1kg |
0.5kg |
1kg |
1kg |
Accuracy |
±1kg |
±1kg |
±2kg |
±1kg |
±1kg |
±2kg |
Forklift arm length (L) |
1150mm |
1220mm |
Forklift arm distance (D) |
220mm |
360mm |
Overall forklift width (H) |
540mm |
680mm |
Weight |
98kg |
105kg |
Material |
mild steel |
Indicator power supply |
rechargeable lead acid battery(6V/4Ah) |
Operation temperature |
-10~50°C |
Operation humidity |
30%~90%RH |
Limited load |
2500kg |
3000kg |
3000kg |
2500kg |
3000kg |
3000kg |
