Dimension Guide for LUTRON Vibration Meter VN-8202 (ISO 2954, Accuracy; ±5%) Range Velocity: 0.01 to 200mm/s (RMS) :
Ordering Guide for LUTRON Vibration Meter VN-8202 (ISO 2954, Accuracy; ±5%) Range Velocity: 0.01 to 200mm/s (RMS) :
ORDER CODE |
VN-8202 |
Display |
61 mm x 34 mm supper large LCD display.
15 mm ( 0.6″ ) digit size. |
Measurement |
Velocity, Acceleration RMS value, Peak value, Data hold, Max. & Min. value. |
Range |
Velocity : 200 mm/s : 0.5 to 199.9 mm/s |
Acceleration : 200 m/s^2 : 0.5 to 199.9 m/s^2 |
Frequency range |
10 Hz to 1 KHz
* Sensitivity relative during the
the frequency range meet ISO 2954. |
Circuit |
Exclusive microcomputer circuit. |
Accuracy |
± ( 5 % + 2 d ) reading , 160 Hz, 80 Hz.
* 23± 5 ℃ |
Calibration point |
Velocity : 50 mm/s ( 160 Hz ) Acceleration : 50 m/s ^2 ( 160 Hz ) |
Data hold |
Freeze the desired reading. |
Peak measurement |
To measure the peak value. |
Memory |
Maximum & Minimum value. |
Power off |
Auto shut off, saves battery life, or manual off by push button. |
Sampling time |
Approx. 1 second. |
Data output |
RS 232 serial output, isolate. |
Operating temperature |
0 to 50 ℃ ( 32 to 122 ℉ ). |
Operating humidity |
Less than 80% RH. |
Power supply |
Alkaline or heavy duty type, DC 9V battery, 006P, MN1604 (PP3) or equivalent. |
Power consumption |
Approx. DC 6 mA. |
Weight |
Meter; 230 g/0.50 LB
|
Probe with sensing head; 165 g/0.36 LB |
Dimension |
180 x 72 x 32 mm ( 7.1 x 2.8 x1.3 inch ). |
Vibration probe : Round 36 mm Dia. x 71 mm. |
Sensing head : 8.9 mm Dia x 42 mm length |
Cable length :1.2 meter. |
Accessories included |
Instruction manual, Cable with plugs, Vibration probe, Sensing head, Magnetic base, Case |
Optional accessories |
* Software ( Windows version, data record & data acquisition )
………………………….. SW-U801-WIN
* RS232 cable. UPCB-01
* USB cable……………… USB-01 |
