Dimension of INSIZE Magnetic V-Blocks 6889 (Advance Type, Force 833N – 3923N) Range; ⌀5mm~⌀140mm:
Ordering Guide INSIZE Magnetic V-Blocks, 6889, Force 833N – 3923N (Individu per PCS):
Single |
Order Code |
Dimensions (LxWxH) |
Measuring range of shaft (Ød0) |
Electromagnetism |
Parallelism of V-groove with top and bottom, right and left |
Perpendicularity between the V-groove and the back surface |
6889-11 |
75x56x75mm |
5-40mm |
85kgf |
5µm |
5µm |
6889-22 |
100x70x95mm |
5-65mm |
150kgf |
5µm |
5µm |
6889-33 |
150x75x100mm |
5-70mm |
190kgf |
6µm |
6µm |
6889-55 |
160x125x130mm |
5-140mm |
220kgf |
12µm |
12µm |
6889-44 |
200x125x150mm |
10-140mm |
400kgf |
12µm |
12µm |
The holding power is based on the V face and ⌀20 round steel bar.
Ordering Guide INSIZE Magnetic V-Blocks, 6889, Force 833N – 3923N (Per-pasang/ 2PCS):
In pairs |
Order Code |
Dimensions (LxWxH) |
Measuring range of shaft (Ød0) |
Electromagnetism |
Parallelism of V-groove with top and bottom, right and left |
Perpendicularity between the V-groove and the back surface |
Height difference between a pair |
6889-1 |
75x56x75mm |
5-40mm |
85kgf |
5µm |
5µm |
5µm |
6889-2 |
100x70x95mm |
5-65mm |
150kgf |
5µm |
5µm |
5µm |
6889-3 |
150x75x100mm |
5-70mm |
190kgf |
6µm |
6µm |
6µm |
6889-5 |
160x125x130mm |
5-140mm |
220kgf |
12µm |
12µm |
12µm |
6889–4 |
200x125x150mm |
10-140mm |
400kgf |
12µm |
12µm |
12µm |
If you require higher accuracy, please contact us at moc.artxelatemobfsctd@selas
