Dimension Guide for ENERPAC Hydraulic Lock-Grip Puller Set LGH3100E (3 Jaw capacity range; ≤931 kN) Jaw Spread; 730mm – 1985mm:
Ordering Guide for METRIC ENERPAC Hydraulic Lock-Grip Puller Set LGH3100E (3 Jaw capacity range; ≤931 kN) Jaw Spread; 730mm – 1985mm.
Order Code |
Capacity (kN) |
Capacity (imperial tons) |
Puller Power Source |
Maximum Spread (mm) |
Minimum Spread (mm) |
Maximum Reach (mm) |
Number of Jaws |
Weight (kg) |
LGH3100B |
931 |
100 |
Hydraulic |
1985 |
730 |
1220 |
3 |
1360 |
LGH364 |
576 |
64 |
Hydraulic |
660 |
230 |
408 |
3 |
139 |
LGH3100E |
931 |
100 |
Hydraulic |
1985 |
730 |
1220 |
3 |
1360 |
LGHNC210 |
92 |
10 |
Hydraulic |
300 |
84 |
215 |
2 |
10 |
LGHNC310 |
92 |
10 |
Hydraulic |
300 |
84 |
215 |
3 |
13 |
LGHNC214 |
125 |
14 |
Hydraulic |
380 |
125 |
260 |
2 |
14 |
LGHNC314 |
125 |
14 |
Hydraulic |
380 |
125 |
260 |
3 |
18 |
LGHNC224 |
215 |
24 |
Hydraulic |
480 |
165 |
336 |
2 |
37 |
LGHNC324 |
215 |
24 |
Hydraulic |
480 |
165 |
336 |
3 |
47 |
LGHNC253 |
467 |
53 |
Hydraulic |
660 |
230 |
408 |
2 |
111 |
LGHNC364 |
576 |
64 |
Hydraulic |
660 |
230 |
408 |
3 |
139 |
Ordering Guide for IMPERIAL ENERPAC Hydraulic Lock-Grip Puller Set LGH3100E (3 Jaw capacity range; ≤931 kN) Jaw Spread; 730mm – 1985mm:
Order Code |
Maximum Operating Pressure (psi) |
Capacity (imperial tons) |
Puller Power Source |
Maximum Spread (in) |
Minimum Spread (in) |
Maximum Reach (in) |
Number of Jaws |
Weight (lbs) |
LGH3100B |
10000 |
100 |
Hydraulic |
78.15 |
28.74 |
48 |
3 |
2998 |
LGH364 |
10150 |
64 |
Hydraulic |
25.98 |
9.06 |
16.06 |
3 |
306.9 |
LGH3100E |
10000 |
100 |
Hydraulic |
78.15 |
28.74 |
48 |
3 |
2998 |
LGHNC210 |
|
10 |
Hydraulic |
11.81 |
3.31 |
8.46 |
2 |
22.66 |
LGHNC310 |
|
10 |
Hydraulic |
11.81 |
3.31 |
8.46 |
3 |
27.94 |
LGHNC214 |
|
14 |
Hydraulic |
14.96 |
4.92 |
10.24 |
2 |
31.24 |
LGHNC314 |
|
14 |
Hydraulic |
14.96 |
4.92 |
10.24 |
3 |
40.04 |
LGHNC224 |
|
24 |
Hydraulic |
18.9 |
6.5 |
13.23 |
2 |
82.28 |
LGHNC324 |
|
24 |
Hydraulic |
18.9 |
6.5 |
13.23 |
3 |
106.04 |
LGHNC253 |
|
53 |
Hydraulic |
25.98 |
9.06 |
16.06 |
2 |
243.76 |
LGHNC364 |
|
64 |
Hydraulic |
25.98 |
9.06 |
16.06 |
3 |
306.9 |
