Technical Guide for INSIZE Adjustable Snap Gauge 2187 Series (Go/No Go Gauge) Range; ≤⌀6mm – ≤⌀300mm:
Order Guide INSIZE Snap Gauge 2187 Series 0-114mm :
Product Code |
Range |
L |
A |
B |
E |
F |
H |
0d ■ |
2187-6 |
0-6mm |
74 |
15 |
17.5 |
12.2 |
27.2 |
71.5 |
7 |
2187-13 |
6-13mm |
85 |
15 |
26 |
12.2 |
27.2 |
79.5 |
12.3 |
2187-19 |
13-19mm |
93 |
15 |
27 |
12.2 |
27.2 |
83 |
12.3 |
2187-25 |
19-25mm |
100 |
15 |
33.5 |
12.2 |
27.2 |
89.5 |
12.3 |
2187-32 |
25-32mm |
111 |
18 |
38.5 |
15.2 |
35.2 |
104 |
15.3 |
2187-38 |
32-38mm |
117 |
18 |
41.5 |
15.2 |
35.2 |
105 |
15.3 |
2187-44 |
38-44mm |
123 |
18 |
44.5 |
15.2 |
35.2 |
109 |
15.3 |
2187-51 |
44-51 mm |
130 |
18 |
48 |
15.2 |
35.2 |
117 |
15.3 |
2187-57 |
51-57mm |
136 |
18 |
45 |
15.2 |
35.2 |
119 |
15.3 |
2187-63 |
57-63mm |
143 |
18 |
50 |
15.2 |
35.2 |
122 |
15.3 |
2187-70 |
63-70mm |
156 |
20 |
58 |
15.2 |
35.2 |
132 |
15.3 |
2187-76 |
70-76mm |
163 |
20 |
60.5 |
15.2 |
35.2 |
137 |
15.3 |
2187-82 |
76-82mm |
169 |
20 |
64.5 |
15.2 |
35.2 |
140 |
15.3 |
2187-89 |
82-89mm |
175 |
20 |
66.5 |
15.2 |
35.2 |
146 |
15.3 |
2187-95 |
89-95mm |
181 |
20 |
69.5 |
15.2 |
35.2 |
149 |
15.3 |
2187-101 |
95-101 mm |
188 |
20 |
70 |
15.2 |
35.2 |
154 |
15.3 |
2187-108 |
101-108mm |
198 |
24 |
79 |
15.2 |
39.2 |
166 |
15.3 |
2187-114 |
108-114mm |
204 |
24 |
81 |
15.2 |
39.2 |
172 |
15.3 |
Order Guide Order Guide INSIZE Snap Gauge 2187 Series 114mm – 300mm:
Product Code |
Range |
L |
A |
B |
E |
F |
H |
0d |
2187-120 |
114-120mm |
210 |
24 |
86 |
15.2 |
39.2 |
179 |
15.3 |
2187-127 |
120-127mm |
217 |
24 |
89.5 |
15.2 |
39.2 |
186 |
15.3 |
2187-133 |
127-133mm |
223 |
24 |
92.5 |
15.2 |
39.2 |
192 |
15.3 |
2187-139 |
133-139mm |
229 |
24 |
95.5 |
15.2 |
39.2 |
197 |
15.3 |
2187-146 |
139-146mm |
235 |
24 |
98.5 |
15.2 |
39.2 |
201 |
15.3 |
2187-152 |
146-152mm |
242 |
24 |
102 |
15.2 |
39.2 |
205 |
15.3 |
2187-163 |
152-163mm |
273 |
21.4 |
106.7 |
18.2 |
39.2 |
211 |
18.3 |
2187-175 |
163-175mm |
273 |
21.4 |
106.7 |
18.2 |
39.2 |
211 |
18.3 |
2187-188 |
175-188mm |
298.5 |
21.4 |
119.7 |
18.2 |
39.2 |
227 |
18.3 |
2187-200 |
188-200mm |
298.5 |
21.4 |
119.7 |
18.2 |
39.2 |
227 |
18.3 |
2187-213 |
200-213mm |
324 |
21.4 |
131.7 |
18.2 |
39.2 |
242 |
18.3 |
2187-225 |
213-225mm |
324 |
21.4 |
131.7 |
18.2 |
39.2 |
242 |
18.3 |
2187-238 |
225-238mm |
349.5 |
21.4 |
144.7 |
18.2 |
39.2 |
250 |
18.3 |
2187-250 |
238-250mm |
349.5 |
21.4 |
149 |
18.2 |
39.2 |
250 |
18.3 |
2187-263 |
250-263mm |
375.5 |
21.4 |
157.7 |
18.2 |
39.2 |
278 |
18.3 |
2187-275 |
263-275mm |
375.5 |
21.4 |
157.7 |
18.2 |
39.2 |
278 |
18.3 |
2187-288 |
275-288mm |
400 |
21.4 |
170.7 |
18.2 |
39.2 |
291 |
18.3 |
2187-300 |
288-300mm |
400 |
21.4 |
170.7 |
18.2 |
39.2 |
291 |
18.3 |
