Order Guide of MITUTOYO Toolmaker’s Microscope HDMI USB camera set 63AAA353:
63AAA059 – HDMI6MDPX camera, including HDMI cable, mouse and simple calculation and reporting software on SD card
63AAA060 – 0.37X C-mount to Eyepiece adapter for TM microscopes
63AAA155 – Mechanical adapter for mounting the HDMI camera on the ocular tube
Dimension Guide of MITUTOYO Toolmaker’s Microscope TM-1005B Digimatic 200x XY Stage:
Alternative Guide of MITUTOYO Toolmaker’s Microscope TM-A505B Digimatic 200x XY Stage:
Model No | TM-505B | TM-A505B | TM-1005B | TM-A1005B |
Order No | 176-818A | 176-820A | 176-819A | 176-821A |
Objective Lens | Standard accessory:2x,Options: 5x, 10x | Standard accessory:2x,Options: 5x, 10x | Standard accessory:2x,Options: 5x, 10x | Standard accessory:2x,Options: 5x, 10x |
Mic Head.Max. Workpiece Height | 4.53in 115mm | 4.53in 115mm | 4.21in 107mm | 4.21in 107mm |
Transmitted illumination | Stepless brightness adjustment, White LED light source, With green filter | Stepless brightness adjustment, White LED light source, With green filter | Stepless brightness adjustment, White LED light source, With green filter | Stepless brightness adjustment, White LED light source, With green filter |
Surface illumination | Oblique single-source type, Stepless brightness adjustment, White LED light source | Oblique single-source type, Stepless brightness adjustment, White LED light source | Oblique single-source type, Stepless brightness adjustment, White LED light source | Oblique single-source type, Stepless brightness adjustment, White LED light source |
Cross travel measuring range | 2 x 2in 50 x 50mm | 2 x 2in 50 x 50mm | 4 x 2in 100 x 50mm | 4 x 2in 100 x 50mm |
Table top size | 16x6in 52x 152mm | 16x6in 52x 152mm | 9.44x6in 240x 152mm | 9.44x6in 240x 152mm |
Usable area of stage glass | 3.8×3.8in 96x96mm | 3.8×3.8in 96x96mm | 6×3.8in 154x96mm | 6×3.8in 154x96mm |
Linear measurement method | Mic Heads Optional | Mic Heads Included | Mic Heads Optional | Mic Heads Included |
Resolution | N/A | .00005″/1µm | N/A | .00005″/1µm |
Micrometer head travel range | N/A | 2″/50mm | N/A | 2″/50mm |
Options for MITUTOYO Toolmaker’s Microscope TM-A505B Digimatic 200x XY Stage:
